4.6 Measuring with More Than One Condition (Multi-measurement)
4-33 ZM2376
Operation of comparator in multi-measurement
When the multi-measurement is enabled, the limit comparison function of the primary and secondary
parameters is also enabled automaticaly. When the multi-measurement is disabled, the limit
comparison function of the primary and secondary parameters is also disabled. The limit comparison
determines pass/fail based on the upper/lower limit value pair of the primary parameter (common to
BIN1 for Bin sorting) and the upper/lower limit value pair of the secondary parameter.
Limit comparison ••• “4.4 Sorting the Part (Comparator)”, “4.5 Connecting to the Part
handler (Handler Interface)”, and separate manual “ZM2376 Instruction Manual (Remote
Control)” :CALCulate:COMParator[:STATe] Command
In the multi-measurement, the limit comparison is performed on the upper/lower limit values of the
primary parameter (BIN1) and the upper/lower limit values of the secondary parameter for each step.
Once the measurement has finished on every enabled step registered in the multi-measurement list,
total comparison is conducted.
Panel display
The comparison result of primary and secondary parameters is displayed for each step.
When the measurement is finished on all the steps, the total comparison result is updated.
Primary parameter comparison result : (each step)
Total comparison result
IN / OUT / SNG / ERR / NC / LoC
Cp:+12.3456µF D:+0.12345 IN 1.00000k (When all steps are finished)
Secondary parameter comparison result : (each step)
Comparison result of each step
The measured value is larger than the upper limit or any error occurs.
: The measured value is within the range of the upper/lower limit values.
The measured value is less than the lower limit value.
Total comparison result (in order of priority)
ERR A measurement error such as signal overload or ALC error occurs.
NC A contact failure occurs.
LoC A Low C error occurs.
OUT Any of primary or secondary parameters failed.
SNG Primary parameters are all acceptable, but secondary parameters are failed.
With the initial setting, OUT is displayed instead of SNG. When you set to suppress
the /OUT OF BINS output in case of the /S-NG output, SNG is displayed as a priority.
IN All measured values are passed.
