7.2 External Dimensions
7-16 ZM2376
7.2 External Dimensions
Figure 7-3 ZM2376 external dimensions
Side view
When stand is used
Warning labels on the cover
Surface treatm
ent
Front panel
: Plastic sheet Ultra light gray (Munsell 6PB9.2/0.1)
Rear panel
: Munsell 8.5PB2.6/0.2
Cover
: Light gray leather tone (Munsell 6PB7.6/1.2 leather tone)
When the LAN option is
mounted
Front view
Rear view
When the LAN option is mounted
