NF ZM2376 - Page 37

3.1 Panel Component Names and Functions
3-3 ZM2376
Figure 3-2 Rear panel
Certification label
Power inlet
Cooling fan
air outlet
Power switch
Push up to turn
the power on,
and push down to
turn it off.
Handler interface connector
Nomenclature
plate
GPIB
connector
RS-232
connector
USB
connector
LAN
connector
(Optional)
Attached when
the LAN option
is included
