3.2 Display at Power “ON” and Initial Settings
3-7 ZM2376
Table 3-1 Setting items and initial values
Setting item
Parameter range
Initial value
INIT
*RST
Setting
memory
Resume
<Measurement range
(including Rdc)>
Automatic selection
OFF(HOLD)|ON
ON
←
←


Range
100mΩ to 1MΩ
100Ω
←
←


<Measurement signal>
Frequency
1mHz to 5.5MHz
1kHz
←
←


Signal level (voltage)
0.01 to 5Vrms
1Vrms
←
←


Constant voltage drive (CV)
OFF|ON
OFF
←
←


Minimum output impedance
6|25|100Ω
25Ω
←
←


Rd 25Ω upper limit range
1|100Ω
1Ω
←
←


Constant current level
1µ to 200mArms
1mArms
←
←


Constant current drive (CC)
OFF|ON
OFF
←
←


Internal DC bias voltage
0 to 5V
0V
←
←


Internal DC bias output
OFF|ON|AUTO|TRACK
OFF
←
←
×
×
Triggered drive
Continuous | Sync.
Continuous
←
←


<Measurement speed>
RAP|FAST|MED|SLOW|
VSLO
MED
←
←


<Averaging>
ON/OFF
OFF|ON
OFF
←
←


Count
1 to 256
1
←
←


<Trigger>
Trigger source
INT|MAN|EXT|BUS
INT (internal)
←
←


Trigger delay time
0.0000 to 999.9999 s
8ms
←
←


Continuous
OFF|ON
ON
←
OFF
×
×
<Multi-measurement>
(LIST) ON/OFF
OFF|ON
OFF
←
←
×

Multi-measurement mode
SEQuence|STEPped
SEQuence
←
←
×

Multi-measurement list
Frequency
{Frequency|OFF} x 32 steps
All OFF
×
×
×

Setting memory
{0 to 31|OFF} x 32 steps
All OFF
×
×
×

<Correction frequency
range>

Correction upper limit
frequency
2kHz to 5.5MHz
2MHz
←
←


Correction lower limit
frequency
1mHz to 100kHz
40Hz
←
←


<SPOT correction>

ON/OFF
OFF|ON
OFF
←
←


Frequency
(automatic)
All disabled
←
←


<OPEN correction>

ON/OFF
OFF|ON
OFF
←
←


Correction value (Primary &
Secondary parameters)
±9.99999E+11
Y-equivalent
0, 0
←
←


Format of correction value
G-B|Cp-G
G-B
←
←


<SHORT correction>

ON/OFF
OFF|ON
OFF
←
←


Correction value (Primary &
Secondary parameters)
±9.99999E+11
Z-equivalent
0, 0
←
←


Format of correction value
Rs-X|Ls-Rs
Rs-X
←
←


