VBA28001-R.3813.A
- A41 ・ D3100 -
#663
#375
#362
#B371
#616
#372
#373
LEN317A
Attach the click ball (#362) and contact brush (#375).
Tighten the two screws (#663).
•
•
Mount the mode dial unit (#B371).
Attach the contact brush (#372) and click spring (#373).
Tighten the screw (#616).
•
•
•
Hook.
[#362] close-up
