Nikon D3100 VBA28001 - Mode.dial.unit

VBA28001-R.3813.A
- D23 ・ D3100 -
#616
#372
#373
#B371
#663
#375
#362
#374
Mode dial unit
Take out the screw (#616).
Remove the contact brush (#372) and click spring (#373).
Remove the mode dial unit (#B371).
•
•
•
Unhook.
Take out the two screws (#663).
Remove the contact brush (#375), click ball (#362), and release mode dial (#374).
•
•
[#362] close-up
