Nikon D3100 VBA28001 - Sb.upper.cover; Sb.lower.cover.unit

VBA28001-R.3813.A
- D17 ・ D3100 -
#459
#305
[Red]
#301
#628
[Green]
[Blue]
[Gray]
[Orange]
#305
[Blue]
SB lower cover unit
Unhook the spring (#305).
Unhook the spring (#459) and spring (#305).
•
•
Unsolder the two wires.
Release the four wires from the four guides.
•
•
SB upper cover
Take out the two screws (#628).
Remove the SB upper cover (#301).
•
•
＝
Guide
