Nikon D3100 VBA28001 - Battery.box.unit

VBA28001-R.3813.A
- D31 ・ D3100 -
#158
#643
#638
[Purple] x2
[Black]
[Red]
Battery box unit
Remove the spring (#158).•
Take out the one screw (#638) and two screws (#643).•
Disconnect the FPC by slightly tilting the battery box sideways.
Unsolder the four wires of the power drive PCB.
Remove the harness.
•
•
•
