Nikon D3100 VBA28001 - Top.cover.fpc.unit

VBA28001-R.3813.A
- D20 ・ D3100 -
#617
#361#362
#B360
#B1007
Top cover FPC unit
Remove the ve solders of the hot shoe.
Take out the three screws (#617).
•
•
Solder×5
Remove the top cover FPC unit (#B1007).•
Caution: When the top cover FPC
unit is removed, be careful that the
inner click spring (#361) and click
ball (#362) in the command dial may
pop out.
