Nikon D3100 VBA28001 - Discharge.of.main.condenser

VBA28001-R.3813.A
- D7 ・ D3100 -
#646
#160
#465
2KΩ/5W
#24
Discharge of main condenser
Take out the two screws (#646) from the front cover (#24).
Remove the spring (#160).
Remove the button (#465).
•
•
•
There are high voltage parts inside. Be careful of this electric shock,
when you remove the cover.
You must discharge the main condenser according to the instruction
of this repair manual after you remove the cover.
WARNING!
