Nikon D3100 VBA28001 - Lcd.unit; G7.Lens.unit

VBA28001-R.3813.A
- D27 ・ D3100 -
#650
#B1045
#291
#271
TA-0026 (4.5×4.5)
①
②
LCD unit
Take out the two screws (#650).
Remove the LCD unit (#B1045) and tape (#291).
•
•
G7 lens unit
Disconnect the FPC’s one end of the AE-CCD, and remove the other end from the shading plate (#271).
Peel off the double-stick tape [TA-0026 (4.5×4.5)].
•
•
