VBA28001-R.3813.A
- D28 ・ D3100 -
#271
#293
#262
#7
#264
#268
Remove the shading plate (#271) and sponge (#293).•
＝
Unhook.
Pull out the pin (#262).
Remove the G7 lens unit.
•
•
Release from the
groove side.
Be careful of pop-
out of the spring.
Pushing from the prism
side will make it easier
to pull out [#262].
User ID:INC
