Nikon D3100 VBA28001 - Front.body; Image.sensor.unit

VBA28001-R.3813.A
- D41 ・ D3100 -
#B3051
#634×3
#87 ~ #107×3
#80×3
#59
Image sensor unit
Peel off the tape (#59).
Take out the three screws (#634), and remove the three washers (#80).
Remove the image sensor unit (#B3051).
Remove the washers (#87-#107).
•
•
•
•
5. Front Body
