Nikon D3100 VBA28001 - Inspection and Adjustment of ∞ (Infinity) Focus; If.holder

VBA28001-R.3813.A
- A36 ・ D3100 -
#633
#70
Inspection and adjustment of "∞ (innity)" focus
Refer to "Inspection and adjustment of "∞ (innity)" focus" of ADJUSTMENT Separate Volume
①
for
details.
Standard: Range fm -0.06 to +0.06mm
-0.06 or smaller: Increase the washers (to increase thickness)
+0.06 or larger: Decrease the washers (to reduce thickness)
•
IF holder
Mount the IF holder (#70), and tighten the screw (#633).•
Tool (Device)
J19001 J18010 J15441
∞ focus collimator F = 600mm Innity standard lens 50/1.8 Innity focus adjustment screen
297A 1K603-712 washer T=0.10
297B 1K603-713 washer T=0.20
