Nikon D3100 VBA28001 - Rear Cover Assembly

VBA28001-R.3813.A
- A51 ・ D3100 -
#405
#405
#404
EDC0021
#408
#470
#471
#472
#619
MZ-310B
4. Rear Cover
SD access lamp window
Attach the SD access lamp window (#408), and apply the adhesive (EDC0021).
TFT sponge
By tting in the groove of the rear cover, attach the two sponges (#404) and two sponges (#405).
•
•
LV lever
Attach the LV lever (#470), spring (#472), and retainer plate (#471). Then, tighten the two screws (#619).•
Dipping
