Nikon D3100 VBA28001 - Af.sensor.unit; Lens.release.button.unit

VBA28001-R.3813.A
- D53 ・ D3100 -
#162
#B2163
#39
#161
#B116 #119
#115
#648 x 2
AF sensor unit
Take out the three screws (#162) with the hexagonal key
（
φ1.5mm).
Remove the AF sensor unit (#B2163).
Peel off the tape (#39) from the AF sensor unit (#B2163).
Remove the three springs (#161).
•
•
•
•
Lens release button unit
