Nikon D3100 VBA28001 - F-Min.sw; Lens.contact.unit

VBA28001-R.3813.A
- D51 ・ D3100 -
#668
#133
#B2113
#650
#138
TA-0009(5×7)
F
-min SW
Peel off the tape [TA-0009 (5×7)].
Remove the solder bridge that joints the F-min SW (#133) and the FPC of the lens contact unit (#B2113).
Take out the screw (#668), and remove the F-min SW (#133).
•
•
•
Lens contact unit
Remove the solder bridge.
Take out the two screws (#650), and remove the GND plate (#138).
•
•
Remove solder
bridge.
Remove solder
bridge.
