Nikon D3100 VBA28001 User Manual

VBA28001-R.3813.A
- A61 ・ D3100 -
Firmware update
Refer to "Firmware update" of ADJUSTMENT Separate Volume
②
for details.•
How to connect camera and PC
Refer to "How to connect camera and PC" of ADJUSTMENT Separate Volume
②
for details.•
How to install inspection and adjustment software for camera body (except imaging)
Refer to "How to install inspection and adjustment software for camera body (except imaging)" of
ADJUSTMENT Separate Volume
②
for details.
•
Tool (Device)
J65153
Camera-body adjustment
software
Inspection and adjustment for AE accuracy
Refer to "
①
Inspection and adjustment for AE accuracy" of ADJUSTMENT Separate Volume
②
for
details.
•
Tool (Device)
J19123 RJ is unavailable J18267 J18498 J18499 Use Nikon product
EF-1 EF-8000 LENS AF50/1.4D Lens AF 28/2.8D Lens AF-S VR
70-300/4.5-5.6
Lens AF
70-300/4-5.6D
Shutter tester 70-300mm lens
J18360
Power supply
（10V 5A)
Digital meter Flashmeter Converted
power connector
EP-5A
Standard reector
J15428 J15443 J15444 J63070 Use Nikon product
AE CCD chart board 2WAY level 2WAY stage Color viewer Power connector
EP-5A
User ID:INC

Nikon D3100 VBA28001 Specifications

General

Model	D3100
Product Code	VBA28001
Category	Digital Camera
Sensor Type	CMOS
Sensor Size	23.1 x 15.4 mm
Effective Pixels	14.2 million
Lens Mount	Nikon F mount
LCD Resolution	230, 000 dots
Viewfinder Type	Optical (pentamirror)
Viewfinder Coverage	95%
Autofocus	11-point AF system
Continuous Shooting	3 fps
Storage Media	SD/SDHC/SDXC
Battery Life	Approx. 550 shots
Dimensions	124 x 96 x 74.5 mm
Max Resolution	4608 x 3072
Image Ratio	3:2
Focal Length Multiplier	1.5x
Articulated LCD	No
Max Shutter Speed	1/4000 sec
Min Shutter Speed	30 sec
Metering Modes	Matrix, Center-weighted, Spot
White Balance Presets	12
USB	USB 2.0
ISO Range	ISO 100 - 3200 (Expandable to 12800)
LCD Screen Size	3 inches
Video Recording	1080p HD at 24 fps
Battery	EN-EL14
Exposure Compensation	±5 EV in 1/3 EV steps
HDMI	Yes (mini HDMI)
