Nikon D3100 VBA28001 - Sub-Frame

VBA28001-R.3813.A
- D37 ・ D3100 -
#147
#657
#145
#62
#63
#63
TA-0016 (5×8)
Sub-frame
Remove the "O"-ring (#147).
Take out the two screws (#657), and remove the eyelet (#145).
•
•
Remove the two rubbers (#63) from the sub-frame (#62).
Peel off the tape [TA-0016 (5×8)].
•
•
