Nikon D3100 VBA28001 - Page 48

VBA28001-R.3813.A
- D43 ・ D3100 -
#612
#2004
#612
#196
#604
#2003
Take out the two screws (#612).
Remove the brake plate (#196).
•
•
Take out the screw (#604).
Remove the retainer plate (#2003).
•
•
Take out the screw (#612).
Remove the retainer plate (#2004).
•
•
