Nikon D3100 VBA28001 - Page 98

VBA28001-R.3813.A
- A39 ・ D3100 -
2KΩ/5W
Remove the battery cover unit (#B151).
Take out the three screws (#631), and remove the front cover (#24).
Discharge the main condenser.
•
•
•
There are high voltage parts inside. Be careful of this electric shock,
when you remove the cover.
You must discharge the main condenser according to the instruction
of this repair manual after you remove the cover.
WARNING!
