Items Judgment standard Remarks
External view
Step
(height difference)
Clearance
Between top cover and apron: 0.2 mm or less
Other parts: 0.3 mm or less
Moving parts: 0.5 mm or less
from Top cover to Apron; to I/F cover: 0.2 mm or less
from Bottom cover to Apron; to I/F cover: 0.2 mm or less
from Top cover to around grip strap eyelet: 0.3 mm or less
from Top cover to around rear cover strap eyelet: 0.4 mm or less
When SB is housed, from SB upper case to Top cover; to Apron: 0.3 mm
or less
Other parts: 0.3 mm or less
Moving parts: 0.5 mm or less
Visual check
Digital micrometer
Size / Force
Shutter release button
Aperture lever
Main mirror
Sub-mirror
∞ Infinity focus
Protrusion: 0.8 ± 0.2 mm
Halfway pressing force: 100 ± 50 g
Halfway pressing stroke: 0.6 ± 0.2 mm
Releasing force: 260 ± 70 g
Releasing stroke: 0.8 ± 0.25 mm
（Half-release pressing ON）
Extra stroke after releasing button: 0.6 mm or more
Difference btwn Half-releasing and Full pressing force:
51 g or more
3.4 height: 3.4 + 0.1 mm
45 ゜ angle: Up-down ± 10'
Right-left ± 30'
Distortion: 8' or less
Clearance for up-mirror in mirror box: None
59 ゜ angle: Up-down 0 ± 20'
Distortion: 8’ or less
±100μm
Digital micrometer
Tension gauge
3.4 height gauge
Collimator
Main mirror tool
Visual check
Feeling in hand
Sub-mirror tool
Collimator
∞ focus lens
Inspection standards
