- Ａ  ･ -
Q0340グラフィック用ロゴ
060411デザイン部伊藤
VBA14001-R.3694.A
#625
#642
#119
#115
A/M change SW cover area
Yellow:Front body FPC
Black:Front body FPC
#B125
#114
・
Solder two wires.
[
Make soldering bridge to joint the black wire, AM change SW
unit (#B125) and the mount GND spring (#114).
]
・
Insert [#119].
・
Mount [#115], and tighten the screws (#642 and #625).
