- Ｄ  ･ -
Q0340グラフィック用ロゴ
060411デザイン部伊藤
VBA14001-R.3694.A
・
Remove the tape (#734).
・
Remove AFCCD-FPC.
・
Take out three screws (#173) with Hexagonal wrench (φ1.5mm)
to remove AFCCD FPC unit (#B2163).
・
Three springs (#170) come off, too.
#734
#173×3
#170×3
AF CCD-FPC
AF CCD FPC unit
(#B2163)
　
AFCCD FPC unit
