Chapter 21 Major Specifications
266
Other
Information
I/O connector
Camera interface LVDS 3 pairs
CF card Type I (only CF cards are supported)
USB (D) connector
(USB 2.0 device interface)
PTP function (PC connection) / Vender unique function (PC connection) /
Direct print function (PictBridge-compatible printer connection)
USB (H) connector
(USB 2.0 host interface)
Two systems
USB memory (FAT16/FAT32-capable), USB mouse, Nikon microscope (upright
microscope Ni/Ci, industrial microscope LV series
(LV150A/LV100DA/LV-ECON/LV-DAF), multi-purpose zoom microscope AZ100M,
inverted metallurgical microscope MA200, wafer inspection microscope L300N/L200N)
DVI-I connector
For connecting external monitors (XGA/SXGA)
VESA DDC2B-compliant, plug & play function-capable
Power jack
For connecting AC adapter
2 pins (polarity: center minus)
10/100Base-T connector
For connecting network (IEEE802.3-compliant, 10Base-T / 100Base-TX,
DHCP-capable)
HTTP server function (web browser display, image transfer)
Telnet server function (DS-L3 control)
FTP server function (image transfer, MIC control)
FTP client function (image transfer)
Power
Input rating 12 VDC ±5%, 2.5 A
Power consumption 70 VA (for connecting DS camera head, DS AC adapter)
Others
Outer dimensions (width x height x
depth)
230 x 200 x 52 mm
Weight Approx. 1.8 kg
Fixed part structure
Standard stand (stand style of free stop hinge)
VESA (75 mm) arm stand / UL1678-applicable stand, fixable to the mount
(The mounting hole is common to the standard stand)
Operating environment
Temperature: 0 to +40°C
Humidity: 60% RH Max. (no condensation)
Altitude: 2000 m Max.
Pollution degree: Degree 2
Installation: Category II
Electric shock protection class: Class I, only for indoor use
Storage environment
Temperature: -20 to +60°C
Humidity: 90% RH Max. (no condensation)
Acoustic Noise
Less than 70 dB
Maschinenlärminformations- Verordnung –3.GPSGV, 06.01.2004: Der höchste
Schalldruckpegel beträgt 70dB(A) oder weniger gemäß EN ISO 7779
