Chapter 8 Capturing Images with Advanced Setting Menu
81
Photographing and
Playing Images
Image modes and sizes that can be selected for each DS camera head
The tables below show image modes selectable for each DS camera head type and details of each image mode.
DS-Fi2
Image mode Read mode Scan method Frame rate
Recommended pixel
count for recording
FULL Frame read Interlace 10 fps 2560 x 1920
2x2 Double integration Interlace 18 fps 1280 x 960
4x4 Quadruple integration Interlace 29 fps 640 x 480
FAST Double speed Progressive 21 fps 1280 x 960
ROI-L Frame ROI Interlace 19 fps 1280 x 960
ROI-S Double speed ROI Progressive 37 fps 1280 x 480
*
Default: FAST
DS-Fi1 / DS-Fi1c
Image mode Read mode Scan method Frame rate
Recommended pixel
count for recording
FULL Frame read Interlace 5.9 fps 2560 x 1920
2x2 Double integration Interlace 10 fps 1280 x 960
4x4 Quadruple integration Interlace 17 fps 640 x 480
FAST Double speed Progressive 12 fps 1280 x 960
ROI-L Frame ROI Interlace 12 fps 1280 x 960
ROI-S Double speed ROI Progressive 23 fps 1280 x 480
*
Default: FAST
DS-Vi1
Image mode Read mode Scan method Frame rate
Recommended pixel
count for recording
FULL All pixels read Progressive 15 fps 1600 x 1200
2x2 Double integration Progressive 27 fps 800 x 600
FAST Double speed Progressive 29 fps 800 x 560
C. SCAN Center scanning Progressive 29 fps 800 x 560
*
Default: FULL
DS-Qi1Mc
Image mode Read mode Scan method Frame rate
Recommended pixel
count for recording
FULL All pixels read Progressive 19 fps 1280 x 1024
2x2 Double integration Progressive 31 fps 640 x 480
4x4 Quadruple integration Progressive 48 fps 320 x 240
ROI-L ROI (720p) Progressive 24 fps 1280 x 720
ROI-S ROI (480p) Progressive 32 fps 640 x 480
*
Default: FULL
DS-Ri1
Image mode Read mode Scan method Frame rate
Recommended pixel
count for recording
FULL All pixels read Progressive 19 fps 1280 x 1024
ROI-L ROI (720p) Progressive 24 fps 1280 x 720
ROI-S ROI (480p) Progressive 32 fps 640 x 480
*
Default: FULL
Image mode selection and annotation/measurement
Selecting [ROI-L], [ROI-S], or [C.SCAN] as the image mode clears all scales, annotations, and measurements on
the screen.
