SCRUB SYSTEM 48Service Manual – Advenger, 2800ST, 3800ST, BR 755, BR 855
Installation
1. Apply Loctite blue 243 threadlocker or equivalent to the threads of each isolator.
2. Install the isolators in the brush head. Position each one so that the color stripe it will be visible when the motor plate is installed.
Torque each nut to 8-10 ft. lbs. (10.8- 13.5 N m). Install the 4 plastic covers over the nuts.
3. Apply Loctite blue 243 threadlocker or equivalent to the threads of each isolator. Install the motor plate and 4 isolator nuts.
Torque each nut to 8-10 ft. lbs. (10.8- 13.5 N m). Ensure that the isolator rubber does not twist when you tighten the nuts.
Visually inspect the color stripe to make sure that it is straight line and not twisted. If it is twisted, loosen the nut and repeat the
procedure. It may be necessary to hold the isolator in position with your hand while tighten the nut.
Color
Stripe
