SCRUB SYSTEM 47Service Manual – Advenger, 2800ST, 3800ST, BR 755, BR 855
Motor Plate and isolators (REV)
Removal
1. Remove the brush head from the machine.
2. Remove the brush motor.
3. Remove the retainers.
4. Remove the motor plate by removing the 4 isolator nuts. Inspect the splash shield and replace if damaged..
5. Flip the scrub head upright and remove each of the isolators from the brush head by removing the attaching nuts.
Remove
Remove
4 isolator
nuts
Inspect
Splash Shield
Isolators
Remove
