WHEEL DRIVE SYSTEM 72Service Manual – Advenger, 2800ST, 3800ST, BR 755, BR 855
Replacing the Rear Wheels
WARNING!
Park the machine on a dry at surface, turn the main key switch Off and disconnect the battery pack at the red Anderson connectors
in the battery compartment.
1 Block the front Drive Wheel (4).
2 Jack the Rear Wheel (9) to be replaced per the instructions at the front of this manual in “Jacking Points” section.
3 To prevent injury, if the rear wheel bearing has frozen, replace the bottle jack with blocks or a jack stand before pounding the wheel.
4 See Figure 38. Use a 17mm socket to remove bolt (A), washer (B) and wheel (C).
5 If the bearing has seized, pound off the wheel and use a bearing puller to remove the inner race from the axle.
6 Apply anti-seize to the inner bearing surface of the new wheel; then replace wheel on axle.
7 Apply anti-seize to the bolt threads before refastening bolt, washer and wheel.
FIGURE 38
