3. ORDER CODE
MultiCONT P – 2 –
EXPANSION CODE ENCLOSURE CODE INPUT CODE OUTPUT CODE POWER SUPPLY CODE
Expandable * R IP 65 wall enclosure W 1 HART unit 1 Display only 0 85 … 255 V AC 1
Standard E 2 HART units 2 1 relay 1 24 V AC / DC 2
IP 65 wall enclosure +
transparent cover
C
4 HART units 4 2 relays 2 85 … 255 V AC Ex 5
8 HART units 8 3 relays 3 24 V AC / DC Ex 6
IP 65 wall enclosure +
transparent cover + logger
D
15 HART units M 4 relays 4
5 relays D Ex: Ex ia
1x 4-20mA Analogue output F
1 relay + 1 x 4-20 mA Analogue output 5
2 relays + 1 x 4-20 mA Analogue output 6
3 relays + 1 x 4-20 mA Analogue output 7
4 relays + 1 x 4-20 mA Analogue output 8
2x 4-20mA Analogue output G
1 relay + 2 x 4-20 mA Analogue output H
2 relays + 2 x 4-20 mA Analogue output J
3 relays + 2 x 4-20 mA Analogue output K
4 relays + 2 x 4-20 mA Analogue output 9
RS 485 interface A
1 relay + RS 485 interface L
2 relays + RS 485 interface M
3 relays + RS 485 interface N
4 relays + RS 485 interface P
5 relays + RS 485 interface E
1x 4-20mA Analogue output + RS 485 interface B
1 relay + 1 x 4-20 mA output+ RS 485 interface R
2 relays + 1 x 4-20 mA output+ RS 485 interface C
3 relays + 1 x 4-20 mA output+ RS 485 interface S
4 relays + 1 x 4-20 mA output+ RS 485 interface T
2x 4-20mA + RS 485 interface U
1 relay + 2 x 4-20 mA output+ RS 485 interface V
2 relays + 2 x 4-20 mA output+ RS 485 interface W
3 relays + 2 x 4-20 mA output+ RS 485 interface X
4 relays + 2 x 4-20 mA output+ RS 485 interface Y
The order code of an Ex version should end in „Ex”.
* The system can be expanded using Relay, Analogue and Universal Interface Modules
