5.7.3.6 Refreshing TOT
Once in the menu, pressing ’OK’ will copy the transmitter’s ’TOT2’ value into the relay’s ’TOTAL’ variable, and then delete the contents of the relay’s ’PULSE’.
The transmitter and the MultiCONT become synchronised.
The update operation is followed by the window below.
Updating TOT
Press OK
5.7.3.7 Testing
Relay operation can be tested as seen below.
Te st 2 4
On
Off
Toggle
Not selected
Selected
Select using
Changing the selection will change
the state of relay immediately
In “toggle” mode, pressing
causes the state of the relay to switch.
