NIVELCO MultiCONT - Wiring of 4-Wire Units (Transmitters with Separate Power Supply)

prw2101a0600p_01  20 / 105
4.2.1.2 Wiring of 4-wire units (transmitters with separate power supply)
85...255 VAC
11.4...28 VAC
11.4...40 VDC
Shielding grounded
at the MultiCONT
I+
I– SH
L–
MultiCONT
250 
Transmitter 1
T 2ransmitter
T 3ransmitter
T 15ransmitter
Shielded twisted
cable pair
Universal interface
USER
RS485
MODULE
RS485
PJK-100
Universal Interface
Modules
