8. FUSE REPLACEMENT
PRW10A02-A
RS485
+
B1 fuse
In order to change the fuse loosen four nuts fastening the front panel, carefully tilt
the front panel forward, such that the cable band is not under tension and replace
the fuse.
Warning! Only use fuses specified in the table below:
The device contains 1 network fuse. Its value depends on the
power supply.
POWER SUPPLY FUSE B1
85…255 V AC 50…60Hz T400mA
11.4…28 V AC 50…60Hz
11.4…40 V DC
T1A
