5.4.12. Report:
This provides information about the system structure. This displays the number of devices (transmitters), relays, current outputs, and modules in the system, and also
the number that can be handled. Binding is when a relay or current output is assigned to a device.
Report 53
Devices:
UIM-s
Relays:
Current outs:
Inputs:
U485:
M485:
Bindings:
Type:
SW type:
SW version:
Serial:
Date:
Working:
Power cnt:
Temp min.:
Temperature:
Temp max.:
002/015
000/032
004/064
002/016
000/000
NO
YES
005/100
PEC2M9
01
01.00
B9718160
2005/11/15
6/18/59
224
18°C
22°C
35°C
2 devices (transmitters) in the loop, max. 15
No. of Universal Interface Modules (PJK-100)
No. of relays (64 = sum of maximal internal and external relays)
No. of current outputs
Other inputs
RS485 u interface
RS485 m interface (needed for UIM functioning)
No. of bindings
Type of MultiCONT
S
ser
odule
oftware type of MultiCONT
Software version of MultiCONT
Serial no. of MultiCONT processor
Date of MultiCONT software update
MultiCONT work time (days/hrs/mins)
No. of MultiCONT "power-on"s
MultiCONT min. temperature
MultiCONT actual temperature
MultiCONT max. temperature
5.4.13. Prog CS
When exiting the menu the device
generates a Frame Check Sequence from
the settings (EXCLUSIVE-OR operation of
bytes)
Prog CS
81
129
