NIVELCO MultiCONT - Wiring of Combined Systems (Containing both 2- and 4-Wire Transmitters)

prw2101a0600p_01  21 / 105
4.2.1.3 Wiring of Combined Systems (containing both 2- and 4-wire transmitters)
Transmitter 1
T Nransmitter
T 1ransmitter
T Mransmitter
85...255 VAC
11.4...28 VAC
11.4...40 VDC
T 2ransmitter
T 3ransmitter
Shielding grounded
at MultiCONT
I+
I–
I+ SH
I–
L+
L–
MultiCONT
250 
+U
s
Shielded twisted
cable pair
Shielded twisted
cable pair
Universal interface
USER
RS485
MODULE
RS485
PJK-100
Universal Interface
Modules
