9.4. ADDITIONAL INFORMATION
9.4.1. Problems that may occur during remote programming:
In the case of integer type parameters, MultiCONT
displays all the four digits even if the case of a given
transmitter only one digit is meaningful. For
example:
PRW:
P12 Error state
14
0002
SE-300:
P12: 2
SE-300 only tests the value of digit „a” value( see Manual), and does not display an error if 1002 is written. It even stores this value. It does not indicate any
operational error, but upon reading this parameter from SE-300 1002 is received which does not have any meaning according to the manual!!!!
9.4.2. MultiCONT transmits the parameters without examining them, and the testing is done by the device.
In the event of an error, if the device does not accept it, then a “HART logical error” box message appears on the display.
9.4.3. Use of Second HART Master ( Hand-Held or HART modem + Eview configuration software)
Normally, there can only be one master in HART systems. Since the MultiCONT is a master, other masters can only be used if if the status of every device is set to
inactive, i.e. the MultiCONT is in listen mode. (see „Main menu”/”Devices”) After this, the other master can be connected to the L- and SH terminals (with a 255 Ohm
sensing resistor inside)
9.4.4. Upon exiting remote programming, the unit tests to see if the transmitter really exited the remote programming mode
(During remote programming „RP” appears on the display of the transmitter). If this is not successful, then the „Stuck in RP mode” box message keeps us informed.
In this case, it is not possible to manually enter programming mode!!
9.4.5. When a transmitter does not respond, then „Response” error is entered into the table, but upon termination of the error
(the device responds), this entry is automatically cleared from the table (and does not need to be acknowledged)
This is also true for „Sensor” error ( noEcho, etc ). The states of the relays and current outputs are not refreshed during this process!!!
9.4.6. Upon exiting the menu, MultiCONT immediately saves the modifications
However, there are events that need to be saved, and this happens every 6 minutes. These include:
Work time and number of state changes of relays
The number of times the MultiCONT was turned on (see: „Main menu”/”MultiCONT config.”/”Report”/”Power count”)
The relevant internal variables, if the function of any relay is „Impulse F”, i.e. RP3 sends a unit pulse to the output, (TOTAL and PULSE, see: „Main
menu”/”Relays”/”Programming”/”deleting TOT”)
9.4.7. The error list is cleared when the device is put off
