Note:
1.
RP3 = 0
RP2 = 12.45
Parameter 23
RP1 =
0001.25
To program the parameter select the relevant parameter in Main menu/Relays/Relay/Program/Parameter using the
buttons, enter the value in between the pointers and press . Programming can only be completed by
pressing
after setting RP3 (even if it is zero or not applicable in the given function!)
2. Inactive relays are de-energized (See: Main menu/Relays).
3. More than one device can be assigned to any of the relays (Main menu/Relays/Program/Source)
4. The result will be the mathematical combination of the sources.
If the measurement mode or dimensions of devices are different MultiCONT will send error message (See 6. Errors, Error messages)
5. The result of the transmitters marked with are added.
6. The result of the transmitters marked with is subtracted from the sum of the result of the transmitters marked with
7. Computes the average of the results of the transmitters marked with
8. If the Error function is selected no (source) assignment is required since errors of all active devices will be monitored.
9. Relay state will not be changed (HOLD) if its assigned source does not reply!
10. The device will indicate program error if:
There are multiple sources with different dimensions
„Impulse F” function is selected, and there are multiple sources or RP3=0
„Alt S” or Sequential function is selected, and more than 8 relays are assigned to one device or the sources are different
(e.g.: PV for 1 relay, and SV for another)
The sources are SV, TV, and QV but the COM3 command is not selected
ALARM, G function is selected and dimensions of the transmitters’ measurement values are different
For a detailed overview of the Programming see Appendix 3.
