Cabel Capacitance (pF / m)
Number of
Transmitters
65 95 160 225
1 2800 2000 1300 1000
5 2500 1800 1100 900
10 2200 1600 1000 800
15 1850 1400 900 700
Shielding of the connecting cable between the transmitter and the controller should be grounded at one end, connected either to the internal or external part of the
earthing screw.
Intrinsically safe (Ex) transmitters should be connected through the terminals L+, L– to the controller. These points are galvanically isolated from the other parts of the
electronics. Power supply for the Ex transmitter is current-, voltage- and power-limited.
