Nokia IP40 - Page 182

14 Working with VPNs
182 Nokia IP40 Security Platform User’s Guide v1.1
6. Do one of the following:
 Download Configuration—to obtain network configuration from a VPN site. This
option automatically downloads the network topology (gateway information and rules)
from the VPN site.
 Specify Configuration—to provide the network configuration manually.
 Route All Traffic—to route all network traffic from the VPN site.
Note
You can download the network configuration only if you are connecting to a Check Point
VPN-1 or Nokia IP40 Satellite X VPN Gateway.
To specify configuration
7. If you chose Specify Configuration in the preceding procedure, a dialog box appears.
8. Enter destination network address and subnet mask of the site to connect.
Note
Obtain destination network and subnet mask from the VPN gateway system
administrator.
9. Click Next.
The Site Name dialog box appears.
10. Enter a name for the VPN site.
11. Click Next.The VPN Site Created window appears.
