Nokia IP40 Security Platform User’s Guide v1.1 191
Figure 11 Nokia IP40 Satellite X to VPN-1
Setting Up Nokia IP40 Satellite X
Configure a VPN tunnel between a Nokia IP40 Satellite X and Check Point VPN-1 server or
gateway.
To configure Nokia IP40 Satellite X
1. Specify the IP address of Nokia IP40 Satellite X on the VPN-1 server.
2. Enter the shared secret (a password that is known to both the IP40 Satellite X and the VPN-
1 Server).
Note
For information about how to set up VPN-1, see the Check Point Virtual Private Network
documentation.
Nokia IP40 Satellite X to Check Point FP3 or DAIP
You can use Nokia IP40 Satellite X as a VPN server to establish a VPN connectivity with Check
Point FP3 server by using Check Point FP3 DAIP object.
Setting Up Check Point FP3
Configure a VPN tunnel between an IP40 Satellite X and Check Point FP3 server.
To set up Check Point FP3
1. Define a DAIP object.
Enable IKE.
2. Use the VPN export tool to create a.p12 certificate from the internal certificate defined for
the DAIP object.
Satellite
Ext: 66.93.53.4/22
Int: 192.168.10.1/22
VPN-1 (Hub)
Ext: 66.93.53.2/22
Int: 192.168.1.1/22
Check Point
Firewall-1 NG
Satellite
Ext: 66.93.53.3/22
Int: 192.168.11.1/22
192.168.10.0/22 192.168.11.0/22
192.168.1.0/22
