Understanding the Nokia IP40 Web GUI
Nokia IP40 Security Platform User’s Guide v1.1 53
Using the Nokia IP40 Security Platform Web-based User Interface
Table 11 Summary of the main components of the Nokia IP40 GUI
Graphical User Interface Details
This section provides details about Nokia IP40 v1.1 graphical user interface (GUI).
Figure 4 Main Components of the Nokia IP40 Security Platform GUI
Note
The Tele 8 license of IP40 does not support all of the features mentioned in the table 12
below. For information on features supported by the Tele configuration, see “Nokia IP40
Security Platform Features” on page 20.
No. Component Description
1. Navigation bar Access various feature sets in the IP40 security platform.
2. Tab bar Access and configure all features in the IP40 security
platform.
3. Wizard Set up quickly the IP40 with the most common settings.
4. Status bar Status after a specific configuration.
5. Help Online help to assist you in configuring the IP40.
