3 Getting Started
54 Nokia IP40 Security Platform User’s Guide v1.1
Table 12 gives the name and functionality of each element in the Nokia IP40 GUI.
Table 12 Names and Functions of the Nokia IP40 GUI Elements
Main Tab Secondary Tabs Description
Welcome Displays Welcome and configuration information.
Reports Event Log Displays the last 100 events in four different
categories: Blue, Red, Orange, and Green.
Active Computers Allows you to view computers on your network.
Active
Connections
Allows you to view current connections between
your network and the external world.
VPN Tunnels Displays a list of established VPN tunnels.
Security Firewall Allows you to control firewall security level.
Servers Allows you to selectively allow incoming traffic
from known applications and Internet services.
Rules Allows you to customize your security policy.
Exposed Host Allows you to define a Demilitarized Zone, i.e. a
computer not protected by firewall.
Services Account Provides information on services available in
your service plan, and allows you to manage
security services.
Network Internet Displays information on network setup and
activity.
My Network Allows you to configure network settings.
Modem Allows you to specify your modem type, dial
mode, and port speed.
Static NAT Allows you to specify a NAT address for a given
IP address.
Static Routes Allows you to specify individual computers that
can connect to the IP40.
Setup Firmware Displays current firmware version and details
Logging Enables you to specify syslog server and syslog
port.
Management Allows you to specify the protocols and
accessing information for the IP40.
