Reservoir/Manifold Assembly
The reservoir/manifold assembly parts vary depending on the size of the
melter: one/two‐pump, three/four‐pump. Refer to the correct parts list for your
melter.
One/Two‐Pump Melter Reservoir/Manifold Parts
See Figure 9‐3.
Item Part Description Quantity Note
— ‐ ‐ ‐ ‐ ‐ ‐ ‐ Assembly, manifold/reservoir, one/two pump —
101 ‐ ‐ ‐ ‐ ‐ ‐ ‐ S Base 1
102 ‐ ‐ ‐ ‐ ‐ ‐ ‐ S Manifold assembly 1 A
103 ‐ ‐ ‐ ‐ ‐ ‐ ‐ S Spacer, manifold to base 4
104 ‐ ‐ ‐ ‐ ‐ ‐ ‐ S Plate, insulator, manifold 1
105 ‐ ‐ ‐ ‐ ‐ ‐ ‐ S Support, hydraulics 2
106 ‐ ‐ ‐ ‐ ‐ ‐ ‐ S Washer, lock, split, M8 24
107 ‐ ‐ ‐ ‐ ‐ ‐ ‐ S Washer, flat, narrow, M8 24
108 ‐ ‐ ‐ ‐ ‐ ‐ ‐ S Screw, socket, M8 x 45 4
109 ‐ ‐ ‐ ‐ ‐ ‐ ‐ S Screw, socket, M8 x 25 20
110 ‐ ‐ ‐ ‐ ‐ ‐ ‐ S Nut, hex, M8 16
111 7400293 S Castor, swivel, 100 mm, 130 kg 2
112 7400294 S Castor, swivel, with lock, 100 mm, 130 kg 2
113 256800 S O‐ring, 26 x 2 2
114 7400132 S O‐ring, Viton, 45 x 2 2
115 ‐ ‐ ‐ ‐ ‐ ‐ ‐ S Reservoir, machined 1
116 ‐ ‐ ‐ ‐ ‐ ‐ ‐ S Screw, socket, M8 x 90 6
117 ‐ ‐ ‐ ‐ ‐ ‐ ‐ S Spring washer, 16 mm OD 6
118 7400339 S Plug, M16, O‐ring, Viton 4
119 7400297 S Service kit, heater, 240V, 800W, 1/2 X 13.75 (all
melter manifolds)
3
120 7400569 S Service kit, heater, 240V, 400W, 1/2 X 13.75
(one/two pump melter reservoirs)
3
121 ‐ ‐ ‐ ‐ ‐ ‐ ‐ S Washer, flat, oversize, M6, 22 OD 12
122 ‐ ‐ ‐ ‐ ‐ ‐ ‐ S Washer, lock, split, M6 12
123 ‐ ‐ ‐ ‐ ‐ ‐ ‐ S Screw, pan, recessed, M6 x 10 12
124 ‐ ‐ ‐ ‐ ‐ ‐ ‐ S Screw, pan, recessed, M3 x 8 2
125 ‐ ‐ ‐ ‐ ‐ ‐ ‐ S Lock washer, external, M3 2
126 7401366 S Thermoswitch, AltaBlue 1
127 ‐ ‐ ‐ ‐ ‐ ‐ ‐ S Deflector, adhesive 1
128 1058990 S Cordstock, 3 mm OD, Viton, 75 D 1
129 900298 S Compound, heat sink, 5 oz tube 1
130 900344 S Lubricant, Never Seez, 8 oz can 1
131 900223 S Lubricant, O‐ring, Parker, 4 oz 1
132 900413 S Sealant, RTV, red, 2.8 oz. tube 1
NOTE A: Refer to Manifold Parts.
