9 Tabular overview of the program procedures Deep Discharge
108 © Nortec Electronics 2018
9.7.2 Program 622: Deep Discharge NiCd Battery SAFT
Name according to manual: Deep Discharge with Cell shorting for SAFT with C
1
22: NiCd Battery SAFT
Select Batteryprocessing:
P6: Deep Discharge
Enter:
Number of cells
Rated capacity
Step 1:
Discharging with C
1
until a voltage of 1 V for each cell is reached.
The connection of an automatic cell scan adapter is required:
Step 2:
Deep discharging with device integrated 1 Ohm resistors over each cell for 12 hours.
End of program
Example:
Connected is a 24 V battery with 40 Ah.
The battery is discharged with 40 A to 20 V. Afterwards the 1 Ohm resistors will be shifted over the
cells.
Time monitoring:
Step 1: Discharging maximum 90 minutes.
