8 Program selection The display screen for program 420
© Nortec Electronics 2018 47
8.5.3 Program 420 Step 3
NiCd battery (manufacturer independent)
Program: Maintenance
P420:S3: TOPPING CHARGE 1
31.05V 00.40A 04.02Ah 003MIN
15.01.15 20:42:43
--
.
-
°C
1 Program number
Kind of treatment 4 = Maintenance
Battery type 20 = NiCd battery (manufacturer independent)
2 Step number = S3
3 Step type = TOPPING CHARGE 1
4 20:42:38 = present time
5 31.05 V = present battery voltage
there is no voltage limit to 31 V.
6 0.40 A = present charging current
The topping charge with 10-hours current
4 Ah/10 h = 0.4 A takes 1.5 hours. The reason
for doing this is to equalize the voltages of the
cells.
7 4.02 Ah The display of the capacity continues
which means the inloaded capacity during
I-CHARGE 1 plus capacity for TOPPING
CHARGE 1.
5
6
7
4
3
2
1
