Time monitoring:
Discharging maximum 90 minutes.
9.1.9 Program 023: Discharge to 23 V NiCd battery NKBN
Name according to manual: Discharge down to voltage of 23 V for НКБН
23: NiCd battery NKBN
 select Batteryprocessing: 
P0: Discharge to 23 V
Enter:
 Number of cells
 Rated capacity
Step 1:
Discharging with 0.4 C
1
until a voltage of 1.15 V for each cell is reached.
In case no automatc cell tester is connected:
Shortly before the end a signal asks for the measurement of the single cells voltages.
Otherwise: cell measurement takes place automatically.
End of program
Example:
Connected is a 24 V battery with 40 Ah.
The battery will be discharged with 16 A to 23 V.
Time monitoring:
Discharging maximum 4 hours.
