9 Tabular overview of the program procedures Charge
72 © Nortec Electronics 2018
9.3.7 Program 220: Charge NiCd battery (manufacturer independent)
20: NiCd battery (manufacturer independent)
select Batteryprocessing:
P2: Charge
Enter:
Number of cells
Rated capacity
Step 1:
Charge with C
1
until charging voltage of 1.55
V × number of cells is reached.
Step 2:
Topping charge C
5
for 1.5 hours.
In case no automatic cell tester is connected:
15 minutens before the end of the topping charge a signal asks for the measurement of the single
cells voltages and to control the electrolyte level.
Otherwise:
15 minutes before the end of the topping charge you are requested to control the electrolyte level.
End of program
Time monitoring:
Charging maximum 90 minutes.
Voltage monitoring:
Monitoring minus ΔU > 30mV/cell during charging, error message:
minus delta U detected
