Nortec UL60 - Program 323: Capacity Test Nicd Battery NKBN

9 Tabular overview of the program procedures Capacity test
© Nortec Electronics 2018 83
9.4.4 Program 323: Capacity Test NiCd battery NKBN
Name according to manual: Control Discharge for НКБН
23: NiCd battery NKBN
 select Batteryprocessing: 
P3: Capacity Test
Enter:
 Number of cells
 Rated capacity
Step 1:
Discharging with C
1
until a voltage of 1 V for each cell is reached.
In case no automatic cell tester is connected:
At voltages 23 V, 22 V and 21 V (values for a 24 V battery) or after 60 minutes a signal - up to 4 times
- requests the measurement of the single cells voltages.
Otherwise: cell measurement is done automatically
After that discharging with C
1
until a voltage of 1 V for each cell is reached.
WARNING NOTE: „Battery discharged“
End of program
Example:
Connected is a 24 V battery with 40 Ah. The battery will be discharged with 40 A to 20 V.
Time monitoring:
Discharging maximum 90 minutes.
