Nortec UL60 - Program 021: Discharge Nicd Battery HAWKER; Program 022: Discharge Nicd Battery SAFT

9 Tabular overview of the program procedures Discharge
56 © Nortec Electronics 2018
9.1.7 Program 021: Discharge NiCd battery HAWKER
Name according to manual: Discharge (without Cell shorting) for HAWKER with C
1
21: NiCd battery HAWKER
 select Batteryprocessing: 
P0: Discharge
Enter:
 Number of cells
 Rated capacity
Step 1:
Discharging with C
1
until a voltage of 1 V for each cell is reached.
In case no automatic cell tester is connected:
After 48 minutes a signal asks for the measurement of the single cells voltages.
Otherwise: cell measurement takes place automatically.
End of program
Example:
Connected is a 24 V battery with 40 Ah. The battery will be discharged with 40 A to 20 V.
Time monitoring:
Discharging maximum 90 minutes.
This program is identical to the program 020.
9.1.8 Program 022: Discharge NiCd battery SAFT
Name according to manual: Deep Discharge (without Cell shorting) for SAFT with C
1
22: NiCd battery SAFT
 select Batteryprocessing: 
P0: Discharge
Enter:
 Number of cells
 Rated capacity
Step 1:
Discharging with C
1
to a voltage of 1 V for each cell.
Example:
Connected is a 24 V battery with 40 Ah. The battery will be discharged with 40 A to 20 V.
End of program
