8 Program selection The display screen for program 420
50 © Nortec Electronics 2018
8.5.6 Program 420 Step 6
NiCd battery (manufacturer independent)
Program: Maintenance
P420:S6: TOPPING CHARGE 2
29.60 00.40A 04.02Ah 002MIN
16.01.15 00:36:13
--
.
-
°
C
1 Program number
Kind of treatment 4 = Maintenance
Battery type 20 = NiCd battery (manufacturer independent)
2 Step number = S6
3 Step type = TOPPING CHARGE 2
4 00:36:13 = present time
5 29.6 V = present battery voltage
6 0.40 A = present charging current
The charging voltage is allowed to exceed
31 V. The cell capacities are equalized.
7 4.02 Ah The capacity continues to be counted.
The main-charge plus topping charge is
4 Ah + 2 minutes 0.4 A = 0.02 Ah;
in total 4.02 Ah.
8 0002 MIN Display of charging time span.
After 115 minutes an acoustic signal sounds.
 The cell voltages must be taken using the cell tester.
 Electrolyte has to be adjusted with destilled water.
